Subclavian Steal Syndrome

Introduction

Figure 1 – Relationship between the subclavian and vertebral arteries

Subclavian steal syndrome is a rare condition causing syncope or neurological deficits when the blood supply to the affected arm is increased through exercise. Subclavian steal is secondary to a proximal stenosing lesion or occlusion in the subclavian artery, typically on the left.

In order to compensate for the increased oxygen demand in the arm, blood is drawn from the collateral circulation, which results in reversed blood flow in the ipsilateral vertebral artery (or less commonly the internal thoracic artery).

The syndrome comprises of both cerebral and upper limb clinical features, however cerebral features are often rarer due to the collateral supply form the contralateral vertebral artery.

Coronary-Subclavian Steal Syndrome

Coronary-Subclavian Steal Syndrome occurs in patients who have undergone an Internal Mammary Artery (IMA) Graft. An increase in oxygen demand in the left arm then steals blood from the IMA leading to cardiac ischaemia.

The condition is twice as prevalent in males and occurs three times more often on the left side compared to the right*.

Stenosis in the subclavian artery is commonly caused by atherosclerosis, however less common causes of the condition include vasculitis, thoracic outlet syndrome (e.g. cervical rib), or complications following aortic coarctation repair

*Interestingly, 1 out of every 50 people have their vertebral artery arising directly from the aortic arch, thereby avoiding any chance of the syndrome developing.




Risk Factors

Due to the offending lesion tending to be an atherosclerosis, the main risk factors for the condition are increasing age, hyperlipidaemia, hypertension, smoking, and diabetes mellitus.


Clinical Features

Some patients will present with arm claudication due to the occluding lesions, such as arm pain or paraesthesia, made worse with arm movement.

Reduced blood supply via the vertebral artery can result in a wide range of cerebral symptoms, including vertigo, diplopia, dysphagia, dysarthria, visual loss, or syncope.


Investigations

Suspected cases should initially be investigated with duplex US scan, which can show the retrograde flow in the affected vertebral artery during exercise. Routine chest radiograph can aid in assessing for any external compression on the subclavian artery causing the syndrome.

Definitive investigation is via CT angiography (Fig. 2) or MR angiography, which will identify the anatomy of the occlusive lesion in the arm and can also help to assess the cerebral vasculature*

*80% of patients with subclavian steal syndrome will also have additional vascular disease in the rest of the cerebral circulation

Figure 2 – CT angiogram of aortic arch, demonstrating a stenosis of the left subclavian artery (red circle) with reduced blood flow distally (purple arrow) and no contrast visible in vertebral artery

Disease Severity Risk Scoring

Risk scoring of subclavian steal syndrome can be classified into three grades:

  • Pre-Subclavian Steal – demonstrating purely a reduced anterograde vertebral flow
  • Intermittent Alternating Flow – antegrade flow occurs in the diastolic phase and retrograde flow occurs in the systolic phase
  • Advanced Disease – there is a permanent retrograde flow

Management

Conservative Management

All patients should be started on anti-platelet and statin therapy, if suitable.

Figure 3 – Angiogram of aortic arch, showing a left subclavian artery stent placed (circle) with distal blood flow (red arrow) and contrast extending into left vertebral artery (green arrow)

Patients should have any modifiable cardiovascular risk factors addressed, such as smoking cessation, weight loss, and optimising diabetic control.

Surgical Management

Occlusions may be treated either through endovascular or bypass techniques. In cases with neurological symptoms, cerebral flow re-establishment must be prioritised over direct treatment of the subclavian stenosis.

Use of percutaneous angioplasty ± stenting (Fig. 3) has reported success rates upwards of 90%, albeit with higher rate of restenosis with worsening disease severity.

Use of bypass should be considered for longer or distal occlusions. Options include carotid-subclavian bypass (5 year patency rates reported at 80%) or axillo-axillary bypass.

Key Points

  • Subclavian steal syndrome occurs secondary to a proximal stenosing lesion or occlusion in the subclavian artery
  • Blood is drawn from the collateral circulation, which results in reversed blood flow in the ipsilateral vertebral artery
  • Patients can present with limb claudication and / or cerebral symptoms
  • Mainstay of investigation is through angiography
  • Patients should have cardiovascular risk factors appropriately managed, with the occlusion treated surgical through endovascular or bypass techniques

Quiz

Question 1 / 3
From which artery does the right subclavian artery branch from?

Quiz

Question 2 / 3
Which of the following is NOT a risk factor for developing subclavian steal syndrome?

Quiz

Question 3 / 3
Which of the following is the best in definitively assessing patients for subclavian steal syndrome?

Results

Further Reading

Subclavian steal syndrome
Potter BJ et al., Circulation
